BDRS
BLATT METAL HOUSING / Forward Curved
Fan components and material properties:
The body and hat are made of electrostatically powder-coated sheet metal. The protective wire cage is made of electrostatic material
powder-coated steel. The motor and fan are connected to the main body via steel supports. The device is easy to handle
Air at max.40 ° C.
Fan structure:
The blades are galvanized and manufactured in aerodynamic structure to ensure a profile and a regular flow. Thanks to its aerodynamic blade structure, it works quietly.
Services:
It operates at a low noise level and is designed to be maintenance-free for long periods of time. Due to the suction and shooting ability, it is possible to dispose of the polluted air in the environment and the fresh air into the environment.
Can be installed in the desired pain. The speed can be adjusted with speed control devices.
Cruise control:
Optional control units can be provided (not included)
For 1-phase products, the speed control can be done with a linear voltage regulator
3-phase products can be controlled with a frequency converter
Areas of use :
BDRS radial fans have low noise levels and high pressure characteristics.
They save space thanks to their compact structure. It is lightweight and easy to assemble. It is corrosion resistant
through its electrostatically painted outer body. It is installed in solid fuel boilers and discharges the fresh air required for combustion
into the combustion chamber.
